New concepts in high-speed machining offer drastic improvements in speed, rigidity and durability over competing machines. Our HM series offers the fastest and most powerful machines in their class, while providing easy access, maintenance and operation. Heavy duty cutting performance is delivered by incorporating a rigid frame of think box-shaped structure to foundation the large linear roller guides designed for very heavy loads. High-speed rotation APC and ATC by synchronization cam (OKK patent) delivers smooth performance and production efficiency.

Product Details

Features & Benefits

  • Direct-turn APC
  • Heavy load capacity linear roller guides
  • Core chilled pre-tensioned and double-anchored ball screws
  • High load capacity feed motors
  • Space saving design for economical use of floor space

Technical Data


X-Axis Travel
55.2" (1400mm)
Y-Axis Travel
43.3" (1100mm)
Z-Axis Travel
39.4" (1000mm)
Table Top to Spindle Nose
1.18" – 44.49" (30mm - 1130mm)


Table Size
39.4" x 39.4" (1000mm x 1000mm)
Table Load Capacity
5500 lbs (2500kg)
Max. Workpiece Size
ø 51.18" (1300mm)
Table Change Time: Cut to Cut
21.0 sec

Feed Rate

Rapid Traverse Rate (X/Y/Z)
1889 in/min (48 m/min)
Cutting Feed (X/Y/Z)
1575 in/min (40 m/min)


Spindle Power
60/35 HP
Spindle Speed
12,000 rpm (OP: 8,000 rpm Three Geared Head 923ft-lbs)
Spindle Taper


Standard Number of Tools
60 (OP: 116/176/236)
Maximum Tool Weight
55 lbs (25 kg)
Maximum Tool Length
19.7" (500 mm)
Maximum Tool Diameter
ø 4.5" (115 mm) / ø 10.6" (270 mm) without tool in adjacent pots
Tool Changing Time- Cut to Cut
5.8 sec (Speed is changeable for heavy-weight tools)


Coolant Tank Capacity
211 gal (800 L)
Machine Weight
55,000 lbs (25,000 kg)
Machine Control
