Nakamura-Tome
WY-150
The WY-150 is a twin spindle machine with two turrets, upper and lower, both with Y-axis. With this configuration, the opportunity exists to drastically reduce cycle times, by offering highly capable features like pinch milling, drilling and turning, as well as unique “off-center” interpolative functions that can be performed on both spindles.
Request Information
Or call 1-877-668-4262
Product Details
Features & Benefits
- Opposing Two-Spindle, 2-Turret Construction
- 48 Tool Stations
- 24 Driven-tool Stations
- 3.54 in Y-axis travel on Upper Turret
- 2.75 in Y-axis travel on Lower Turret
- 6,000 min-1 Driven-tool Speed (Upper / Lower)
- 20/15 HP Left and Right Spindle Motor
- 7.5 HP x2 Driven-tool Motor (Upper / Lower)
- 2.5 in Bar Capacity
Technical Data
CAPACITY
- Max Turning Diameter
- 8.8 (225) in (mm)
- Max Turning Length
- 22.24 (565) in (mm)
- Slide travel (X)
- 6.31 (160) in (mm)
- Slide travel (Y)
- 2.74 (70) in (mm)
- Slide travel (Z)
- 22.2 (564) in (mm)
LEFT SPINDLE
- Spindle Speed
- 4500 rpm
- Spindle Speed Range
- Stepless
- Spindle Nose
- A2-6
- Hole Through Draw Tube
- 2.5
RIGHT SPINDLE
- Spindle Speed
- 5000 rpm
- Spindle Speed Range
- Stepless
- Spindle Nose
- A2-5
- Hole Through Draw Tube
- 2.0
TURRET
- Number of Tool Stations
- 24
- Number of Indexing Positions
- 24
DRIVE MOTOR POWER
- Main Spindle
- 20 H/P
- Right Spindle
- 20 H/P
- Driven Tool Spindle
- 7.5 H/P
GENERAL
- Machine Weight
- 23153 (10502) lbs (kg)
